产品型号 | R500/105-3.9SOA | R500/105-4.8SOA | R500/105-5.2SOA | R500/105-6.2SOA | R500/105-5.2SOA | |
像素间距 | 3.91mm | 4.81mm | 5.21mm | 6.25mm | 7.81mm | |
像素构成 | SMD2525 | SMD2727 | SMD2727 | SMD2525 | SMD3535 | |
像素密度 | 65536dot/m² | 43222dot/m² | 36864dot/m² | 65536dot/m² | 16348dot/m² | |
模组分辨率 | 64x64dot | 52*52/dot | 48x48dot | 40x40dot | 32x32dot | |
箱体尺寸 | 500x500X75mm 500x1000X75mm | 500x500X75mm 500x1000X75mm | 500x500X75mm 500x1000X75mm | 500x500X75mm 500x1000X75mm | 500x500X75mm 500x1000X75mm | |
重量 | 7KG,12KG | 7KG,12KG | 7KG,12KG | 7KG,12KG | 7KG,12KG | |
防水等级 | IP65 | IP65 | IP65 | IP65 | IP65 | |
扫描方式 | 16S | 13S | 8S | 5S | 4S | |
亮度水平 | 》5000CD/m² | 》5000CD/m² | 》5000CD/m² | 》5000CD/m² | 》5000CD/m² | |
可视角度 | 140°/140° | 140°/140° | 140°/140° | 140°/140° | 140°/140° | |
观看距离 | >5m | >6m | >7m | >8m | >10m | |
灰度等级 | 14bit | 14bit | 14bit | 14bit | 14bit | |
色彩种类 | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | |
最大功率 | 750W/m² | 630W/m² | 850W/m² | 970W/m² | 780W/m² | |
平均功率 | 250W/m² | 210W/m² | 280W/m² | 324W/m² | 260W/m² | |
刷新率 | ≥1920HZ | ≥1920HZ | ≥1920HZ | ≥1920HZ | ≥1920HZ | |
伽马系数 | -5.0~+5.0 | -5.0~+5.0 | -5.0~+5.0 | -5.0~+5.0 | -5.0~+5.0 | |
使用环境 | outdoor | outdoor | outdoor | outdoor | outdoor | |
亮度调节 | 0 - 100 levels adjustable | |||||
控制方式 | Synchronous display with control PC by DVI | |||||
信号输入类型 | Composite,S-Vido,Component,VGA,DVI,HDMI,HD_SDI | |||||
输入电源 | AC100~240 50/60HZ | |||||
工作温度 | - 20℃~+50℃ | |||||
工作湿度 | 10~95% RH | |||||
工作寿命 | 100,000hours |
